Description
| Usage/Application | Industrial |
| Brand | Castle |
| Color | blue |
| Material | Mild Steel, Stainless Steel |
| Surface Treatment | Powder Coated, Paint Coated |
| TEMPERATURE RANGE | -46/+150 C |
| Power Source | Electric |
Butt-weld ANSI
- DN 15-40(B 36.10 Schedule 80)
- Butt-weld ANSI
- DN 50(B 36.10 Schedule 40)
- Butt-weld ANSI
- Socket weld (ANSI B 16.11)
- DN 15-50 (V2- 1 in.)
Valve cone
The valve cone is designed to ensure perfect regulation. A cone seal ring provides perfect sealing at a minimum closing momentum.
The valve cone can be turned on the spindle, thus there will be no friction between the cone and the seat when the valve Is opened and closed.
Spindle
Made of polished stainless steel so that PTFE and Graphite gaskets are not damaged.
Packing gland – CREG
The “full temperature range” packing gland ensures perfect tightness in the whole range: -46/+150°C
Installation
Install the valve with the spindle up or in horizontal position. The flow must be directed towards the cone.
The valve is designed to withstand high internal pressure. However, the piping system in general should be designed to avoid liquid traps and reduce the risk of hydraulic pressure caused by thermal expansion.
For further information refer to installation instruction for CREG.
Technical data
Refrigerants
Applicable to all common non flammable refrigerants including R 717 and non corrosive gases/liquids dependent on sealing material compability. Flammable hydrocarbons are not recommended. For further information please contact your local Castle Sales Distributor.
Temperature range
CREG: -46/+15(TC
For further information please see installation instruction for CREG
Pressure range
Max. operating pressure: CREG: 40 bar g (580 psig).
Additional Information:
- Item Code: CREG
