Display

Display(Amber): 14 Segment 4 Digit, Display(Green): 7 Segment 4 Digit

Power Supply

3 Phase 4 Wire 415Vac ±10%, 50/60Hz

Probe Input

5 NTC

Temperature Range

-50.0°C to 50.0°C or -50°C to 50°C

Resolution

0.1°C or 1°C (Settable)

CT Input

0 to 20.0A (CT: Comp R-Phase, Y-Phase, B-Phase, Evap-1 & Evap-2 )

Resolution

0.1A

Digital Input

Potential Free: Door Input; Potential(230V): (HP, LP, SPPR, AUX1, AUX2, R-Phase, Y-Phase, B-phase)

Relay Output

Condenser Fan – 20(8)A/230 VAC Evaporator Fan2 – 5A/230 VAC Defrost2 – 5A/230 VAC LSV- 10A/230VAC Light- 5A/230VAC

Alarm Output / Buzzer

Alarm 5A & Internal Buzzer

Contactor

Compressor Contactor: 3 Pole + 1 Aux, 400 V, 18A (230Vac Coil), Defrost Contactor: 3 Pole + 1 Aux, 400 V, 18A (230Vac Coil), Evaporator Contactor: 3 Pole + 1 Aux, 400 V, 9A (230Vac Coil)

Communication

2 x RS-485 Serial port with Modbus RTU Protocol

Other Connectivity

Wi-Fi: Parameter setting via Web server/IoT

Special Feature

SD Card: For Downloading logged data & fault from flash memory RTC: Real Time Clock for Defrost, Energy saving, Data logging & Display in HH:MM

LVM

4 Wire Voltage Monitoring & Protection

Size

400(W) x 300(H) x 135(D)mm

Mounting Type

Wall Mount
